Isuzu NPR 700P New Euro 6 Truck with Diesel 4HK1 Engine
- Category： N-Series Light Trucks
- Loading capacity: 6-8 tons
- Engine model: 4HK1
- Engine power: 139kw
- Gear box: MLD-6Q
Efficient Loading:
Large-capacity cargo box, extremely high space utilization.
Stable Structure:
Isuzu chassis, stable and efficient for city delivery.
Reliable & Durable:
Isuzu-built 4HK1 series engine, over 500,000 km without major repairs.
|
S/N
|
ITEM |
SPECIFICATION
|
|||
|
1
|
Vehicle Model
|
QL5110XXYANPH
|
QL5110XXYANPW
|
QL5120XXYAJHA
|
QL5120XXYANPA
|
|
2
|
GVW(kg)
|
10550
|
10550
|
11995
|
11995
|
|
3
|
Curb Weight(kg)
|
5360
|
5165
|
4650
|
5700
|
|
4
|
Axle Loads(kg)
|
3500/7050
|
3500/7050
|
4000/7995
|
4000/7995
|
|
5
|
Cabin
|
Isuzu cab, high-roof, left-hand drive,
with Air-conditioner, 3 passengers
|
|||
|
6
|
Overall Dimension(mm)
|
8955×2400×3385,3465
|
8355×2300×3400,3300
|
6285×2520,2380×3540
|
8935×2400×3540
|
|
7
|
Box Dimension(mm)
|
6688×2300×2300
|
5200×2200×2300,2200
|
4300×2450,2300×2300
|
6965×2300×2300
|
|
8
|
Wheelbase(mm)
|
5200
|
5200
|
3365
|
5150
|
|
9
|
Engine
|
4HK1-TCG61
|
4HK1-TCG60
|
4HK1-TCG61
|
4HK1-TCG60
|
|
10
|
Engine Output (kW(PS))
|
(139kW)190PS
|
|||
|
11
|
Displacement(L)
|
5.193
|
|||
|
12
|
Emission Standard
|
Euro 6
|
|||
|
13
|
Braking Mode
|
Air Brake
|
|||
|
14
|
Max Speed(km/h)
|
110
|
|||
|
15
|
Front/Rear Overhang(mm)
|
1110/2645
|
1110/2045
|
1160/1760
|
1160/2625
|
|
16
|
Tire Model
|
235/75R17.5 16PR,8.25R20 14PR
|
235/75R17.5 16PR
|
8.25R20 16PR
|
8.25R20 16P
|
